Quick Start • 5 min read

Want to install low-voltage landscape lighting but aren't sure where to start?

The good news is that a basic 12V landscape lighting system is easier to understand than it may seem. You need the right fixtures, an appropriately sized transformer, low-voltage cable, weather-resistant connections, and a thoughtful plan for where your lights should go.

This Quick Start Guide walks you through the basic process so you can start planning your project with confidence.

For detailed installation instructions, transformer sizing, wiring considerations, voltage-drop guidance, and troubleshooting, see our Complete Low-Voltage Landscape Lighting Installation Guide.

Step 1: Decide What You Want to Light

Before buying fixtures, walk around your property after dark and identify the areas that would benefit most from lighting.

Common areas include:

Walkways and pathways
Front entrances
Driveways
Trees
Garden beds
Columns and architectural features
Patios and outdoor living areas
Retaining walls
Steps and decks

Don't try to illuminate everything.

Good landscape lighting uses a combination of light and shadow to highlight important areas while creating depth throughout the property.

Quick Tip: Start with safety and focal points. Illuminate walkways and steps first, then identify the trees, architecture, and landscape features you want to showcase.

Step 2: Choose the Right Fixtures

Different landscape lighting fixtures are designed for different purposes.

Path Lights

Use along walkways, garden paths, driveways, and planting beds.

Spot Lights / Up Lights

Use to highlight trees, columns, architectural features, and other focal points.

Well Lights

Use for discreet uplighting when you want the fixture to remain less visible within the landscape.

Flood Lights

Use when you need broader illumination across larger trees, walls, or landscape areas.

Hardscape Lights

Install beneath retaining wall caps, outdoor kitchen counters, seating walls, and other masonry features.

Step & Deck Lights

Use on stairs, decks, posts, and vertical surfaces where additional visibility is needed.

Most attractive landscape lighting designs use several fixture types together rather than relying on one style throughout the property.

Step 3: Sketch Your Lighting Plan

Make a simple drawing of your property and mark:

Transformer location
Fixture locations
Walkways
Trees
Landscaping
Outdoor living areas
Proposed cable routes

Your sketch doesn't need to be perfect. Its purpose is to help you estimate how many fixtures you'll need and how the system will be organized.

For larger properties, divide the project into zones such as:

Front Entry • Walkways • Trees • Backyard • Patio

This makes installation and future expansion easier.

Step 4: Calculate Your Total Wattage

Every fixture or LED lamp consumes a certain number of watts.

Add the wattage of all the lights in your planned system.

For example:

8 path lights × 4W = 32W

6 up lights × 6W = 36W

4 hardscape lights × 3W = 12W

Total connected load = 80W

You'll use this number to help determine the appropriate transformer capacity.

Step 5: Size Your Transformer

The transformer converts standard household power into the low-voltage electricity used by your landscape lighting system.

A useful planning guideline is:

Total Fixture Wattage ÷ 0.80 = Minimum Transformer Capacity

Using the 80-watt example:

80W ÷ 0.80 = 100W

You would therefore select a transformer with at least 100 watts of appropriate capacity.

If you expect to add more lights in the future, consider selecting the next suitable transformer size so the system has room to expand.

Always follow the specifications and installation instructions for the transformer you're using.

Step 6: Plan Your Cable Runs

Low-voltage landscape cable carries electricity from the transformer to your fixtures.

Rather than automatically placing every light on one extremely long cable run, larger systems may benefit from multiple runs back to the transformer.

This can help with:

Voltage management
Troubleshooting
System organization
Future expansion

Wire gauge, cable length, fixture load, fixture distribution, and system layout can all affect voltage at the fixtures.

For detailed guidance on cable runs and voltage drop, refer to our Complete Low-Voltage Landscape Lighting Installation Guide.

Step 7: Lay Everything Out Before You Dig

Before burying cable or permanently installing fixtures, lay out the system above ground.

Place your fixtures approximately where you want them and route the cable along the planned paths.

This gives you a chance to make adjustments before installation becomes more difficult.

Leave some extra cable near fixtures and connections so lights can be repositioned or serviced later.

Always call 811 before digging.

Cable should be installed according to its manufacturer instructions and applicable local requirements. Do not assume that one burial depth applies to every installation.

Step 8: Install and Connect Your Fixtures

Secure each fixture according to its installation instructions.

If the fixture uses a replaceable LED lamp, install the appropriate lamp type and wattage.

Make all cable connections using connectors designed and listed for the intended outdoor or direct-burial application.

Outdoor landscape lighting connections are exposed to moisture, irrigation, soil, and changing temperatures, so properly installed weather-resistant connections are essential for long-term reliability.

Step 9: Test Before Finishing

Once your connections are complete and you've performed the appropriate safety checks, power on the system.

Make sure every fixture works before completing cable burial or restoring the landscape.

Check for:

Lights that aren't working
Unusually dim fixtures
Flickering
Loose connections
Noticeable brightness differences

Long cable runs and higher electrical loads can contribute to voltage drop. More complex systems may require voltage measurements at the fixtures while the system is operating.

Step 10: Make Final Adjustments After Dark

Don't consider the installation finished until you've seen it at night.

Walk around the property and adjust each fixture.

Look for:

Glare
Uneven lighting
Fixtures aimed too high
Overly bright areas
Important features that need more emphasis

Sometimes moving a fixture only a few inches or slightly changing its angle can dramatically improve the effect.

Remember: professional-looking landscape lighting isn't about making everything bright.

It's about directing light where it creates the greatest visual and functional impact.

Your Quick-Start Checklist

Before calling the project complete, make sure you have:

Need More Installation Detail?

This Quick Start Guide covers the fundamentals, but larger landscape lighting systems require additional planning.

Our Complete Low-Voltage Landscape Lighting Installation Guide goes deeper into:

Transformer sizing
Cable planning
Voltage drop
Multi-tap transformers
Weather-resistant connections
Voltage testing
Fixture aiming
Common installation mistakes
DIY vs. professional installation

Read the Complete Installation Guide →

You can also download our Free Landscape Lighting Installation Checklist to use while planning and installing your system.

Download the Free Installation Checklist →

Start Planning Your Landscape Lighting Project

A great landscape lighting system starts with a good plan.

Begin with the areas that matter most, choose fixtures based on the lighting effect you want to create, and leave room for your system to grow.

Whether you're illuminating a simple front walkway or planning lighting throughout an entire property, thoughtful fixture placement and quality components can make a dramatic difference in the finished result.
